Acoustic Movable Partition Wall with Dupont POM Roller and Top & Bottom Jack Lifting Mechanism

Acoustic Movable Partition Wall with Dupont POM Roller and Top & Bottom Jack Lifting Mechanism

Наименование марки: AE
Номер модели: AE65
МОК: 10 квадратных метров
цена: USD 79-108 per square meter
Условия оплаты: Т/Т,Л/К,Вестерн Юнион
Возможность поставки: 1000 квадратных метров в месяц
Подробная информация
Место происхождения:
Гуандун, Китай
Сертификация:
ISO9001 SGS CANS
Ряд::
Передвижная перегородка
Базовая доска:
ОГНЕУПОРНАЯ ДОСКА
Согласие:
конференц-зал
Толщина:
68cm
Рейтинг STC:
42-56 дБ
Размеры:
Настройка (Высота: до 4,5 м, Ширина на панель: до 1,2 м)
Имя:
Передвижная перегородка
Упаковывая детали:
пенопластовый слой и твердый картон с фанерным корпусом или стальным поддоном
Выделить:

Dupont POM Roller Movable Partition Wall

,

Top & Bottom Jack Lifting Mechanism Sliding Wall Panels

,

Magnetic Seal Operable Partition Wall

Описание продукта
Acoustic Movable Partition Wall Systems with Sliding Wall Panels
High quality AE operable partition walls are suitable for spaces that need to be divided quickly into different sections. These versatile systems transform spaces into multifunctional areas that can be configured as closed or open environments as needed.
Key Features
  • German Partition Technology Global Professional Space Solutions
  • Highly competitive pricing
  • Rigorous quality control
  • Efficient communication
  • State-of-the-art technology products
  • Experienced, English-speaking support staff
  • Custom manufacturing available to match your design specifications
Roller Options & Features
  • Dupont POM rollers
  • 304 stainless steel heavy duty rollers with safety device & CNC machining
  • Patented wheel surface and shape design for smooth operation
Panel Options & Features
  • Available thicknesses: 68mm, 89mm, and 105mm
  • Wide selection of acoustical and decorative finishes
  • 6061-T6 profile with Q235 steel frame for enhanced durability
  • Top & bottom jack lifting mechanism seal with 800N power
  • Magnetic seal in concave & convex profile with 40N/m magnetic attraction
Technical Specifications
Series Element thickness (mm) Element width (min/max mm) Clear height (min/max mm) Construction Panel fixing Element interconnection
AE65 68 600/1,250 2,000/4,500 Aluminium-steel Freely oscillating Aluminium profile with magnetic strip and sealing lips
AE85 89 600/1,250 2,000/5,500 Aluminium-steel Freely oscillating Aluminium profile with magnetic strip and sealing lips
AE100 105 600/1,250 2,000/18,000 Aluminium-steel Freely oscillating Aluminium profile with magnetic strip and sealing lips
Technology: Weighted sound reduction value (Rw) determined per GB/T19889.3-2005: 52/56 dB
Connection system: Positive and frictional locking with convex-concave profile form, magnetic strip attraction force of 40 N/m
* Larger widths available upon request. Final dimensions subject to Design Department confirmation.
